16埠桌上型超高速網路交換器-GS316
提供家庭/商辦場所更多的
Gigabit超高速網路連接埠
金屬外殼
有效提高散熱及穩定度
體積輕巧不占空間，隨插即用
IEEE802.3az高效節能標章，省電又環保
NETGEAR GS316桌上型超高速網路交換器 專為SOHO族與中小企業所設計，提供穩定、高速的有線網路頻寬。 GS316外殼為金屬材質，散熱效果極佳，無風扇式設計安靜無噪音，使您可專注於工作之上。
GS316體積輕巧，可平放於桌面使用，提供工作場所擴充的網路埠口連接更多有線網路設備，快速傳輸大量檔案，增進工作效率，是辦公室、校園、會議中心的最佳選擇。
| Features | GS316 |
| 10/100/1000Mbps Ports (Auto Uplink) | 16 |
| Enclosure | Metal |
| Connector Type | Metal |
| Form Factor | Desktop or wall-mountable |
| Power On/Off Switch | No |
| 效能規格 | |
| Bandwidth (Non-Blocking) | 32 Gbps |
| Packet Buffer Memory (Dynamically shared across only used ports | 768 KB |
| Jumbo Frame Support | 9,216 bytes |
| Queue WRR (Weighted Round Robin) Ratio | 1:2:4:8 |
| Forwarding Rate (using 64-byte packets) - 1000Mbps Port | 1,448,000 pps |
| Latency (using 64-byte packets) - 1000Mbps Port (average) | < 3.9 µsec |
| MAC Address Table Size | 16K |
| Auto MDI/MDI-X Cable Detection | Yes |
| Auto-sensing Half/Full Duplex Switched Ports | Yes |
| Mean Time Between Failures (MTBF) @ 25° C | 9,041,798 hours |
| LEDs提示燈 | |
| Per port | Speed, Link/ Activity |
| Per device | Power |
| Quality Of Service (QOS) | |
| Energy Efficient Ethernet (IEEE 802.3az) | Yes |
| Auto Power Down | No |
| PoE效能 | |
| 802.3af PoE Ports | n/a |
| PoE Max Power Per Port | n/a |
| Total PoE Power Budget** | n/a |
| 電源功耗 | |
| DC Input/Power In | 12V / 1.0A |
| Power Consumption (Max and Standby) | 8.4W/1.83W |
| Heat Dissipation (Max and Standby) (BTU/Hr) | 28.73 BTU/ 6.26 BTU |
| 電源效能 | |
| Energy Efficient Ethernet (EEE) IEEE 802.3az compliant | Yes |
| Auto Power Down | Yes |
| Short Cable Detection | Yes |
| Fan/Fanless | Fanless |
| 體積與重量 | |
| Width x Depth x Height | 286 x 101 x 26 mm (11.3 x 4.0 x 1.0 in) |
| Weight | 0.84 kg (1.86 lb) |
| 環境需求 | |
| 運作環境 | |
| Operating temperature | 0° to 40°C (32° to 104°F) |
| Humidity (relative) | 90% maximum relative humidity (RH), non-condensing |
| Altitude | 10,000 ft (3,000 m) maximum |
| 儲藏環境 | |
| Storage temperature | –20° to 70°C (– 4° to 158°F) |
| Humidity (relative) | 95% maximum relative humidity (RH), non-condensing |
| 電磁輻射干擾與耐受性 | |
| Certifications | CE Mark, FCC Part 15 Class A, IC Class A, RCM, CCC, VCCI, KC |
| 安全認證 | |
| Certifications | CB, CE LVD, CCC |
| 網路通訊協定與標準相容 | • IEEE 802.3ab 1000BASE-T Gigabit Ethernet • IEEE 802.3u 100BASE-TX Fast Ethernet • IEEE 802.3i 10BASE-T Ethernet • IEEE 802.3x Flow Control • IEEE 802.1p Priority QoS (all models) • IEEE 802.1p Priority QoS and DSCP (except GS308P, GS316) • IEEE 802.3 CSMA/CD • 802.3az Energy Efficient Ethernet |
| 保固 | 三年 |
如規格有異動，恕不另行通知。NETGEAR保有所有權利。
GS316 規格
| Features | GS316 |
| 10/100/1000Mbps Ports (Auto Uplink) | 16 |
| Enclosure | Metal |
| Connector Type | Metal |
| Form Factor | Desktop or wall-mountable |
| Power On/Off Switch | No |
| 效能規格 | |
| Bandwidth (Non-Blocking) | 32 Gbps |
| Packet Buffer Memory (Dynamically shared across only used ports | 768 KB |
| Jumbo Frame Support | 9,216 bytes |
| Queue WRR (Weighted Round Robin) Ratio | 1:2:4:8 |
| Forwarding Rate (using 64-byte packets) - 1000Mbps Port | 1,448,000 pps |
| Latency (using 64-byte packets) - 1000Mbps Port (average) | < 3.9 µsec |
| MAC Address Table Size | 16K |
| Auto MDI/MDI-X Cable Detection | Yes |
| Auto-sensing Half/Full Duplex Switched Ports | Yes |
| Mean Time Between Failures (MTBF) @ 25° C | 9,041,798 hours |
| LEDs提示燈 | |
| Per port | Speed, Link/ Activity |
| Per device | Power |
| Quality Of Service (QOS) | |
| Energy Efficient Ethernet (IEEE 802.3az) | Yes |
| Auto Power Down | No |
| PoE效能 | |
| 802.3af PoE Ports | n/a |
| PoE Max Power Per Port | n/a |
| Total PoE Power Budget** | n/a |
| 電源功耗 | |
| DC Input/Power In | 12V / 1.0A |
| Power Consumption (Max and Standby) | 8.4W/1.83W |
| Heat Dissipation (Max and Standby) (BTU/Hr) | 28.73 BTU/ 6.26 BTU |
| 電源效能 | |
| Energy Efficient Ethernet (EEE) IEEE 802.3az compliant | Yes |
| Auto Power Down | Yes |
| Short Cable Detection | Yes |
| Fan/Fanless | Fanless |
| 體積與重量 | |
| Width x Depth x Height | 286 x 101 x 26 mm (11.3 x 4.0 x 1.0 in) |
| Weight | 0.84 kg (1.86 lb) |
| 環境需求 | |
| 運作環境 | |
| Operating temperature | 0° to 40°C (32° to 104°F) |
| Humidity (relative) | 90% maximum relative humidity (RH), non-condensing |
| Altitude | 10,000 ft (3,000 m) maximum |
| 儲藏環境 | |
| Storage temperature | –20° to 70°C (– 4° to 158°F) |
| Humidity (relative) | 95% maximum relative humidity (RH), non-condensing |
| 電磁輻射干擾與耐受性 | |
| Certifications | CE Mark, FCC Part 15 Class A, IC Class A, RCM, CCC, VCCI, KC |
| 安全認證 | |
| Certifications | CB, CE LVD, CCC |
| 網路通訊協定與標準相容 | • IEEE 802.3ab 1000BASE-T Gigabit Ethernet • IEEE 802.3u 100BASE-TX Fast Ethernet • IEEE 802.3i 10BASE-T Ethernet • IEEE 802.3x Flow Control • IEEE 802.1p Priority QoS (all models) • IEEE 802.1p Priority QoS and DSCP (except GS308P, GS316) • IEEE 802.3 CSMA/CD • 802.3az Energy Efficient Ethernet |
| 保固 | 三年 |
如規格有異動，恕不另行通知。NETGEAR保有所有權利。
