校園、飯店
大型辦公空間
挑高空間等都適用
無法單獨使用需搭配WAC540
雲端+智能管理
兩用機
與NETGEAR雲交換器
同一平台管理容易
完整APP
管理介面支援
可Insight app
隨時進行管理
三頻 4×4
802.11ac Wave 2
4個連接埠口
支援MU-MIMO
可透過
Netgear Insight 雲端
在Web/APP設定管理
取代傳統無線控制器
節省時間
流量異常通知
視覺圖表介面
三頻 4×4 MU-MIMO 可以支援更多無線設備
WAC564具備
WiFi接入點、單網狀延伸器、網狀網路
三種模式。
支援與WAC540連接Mesh中繼功能
FastLane3
5G 專屬無線延伸通道
高速、低衰減
不需要網路線 可以跨區連接
提供4個乙太網路連接埠口
可以連接印表機、IP電話…等設備
APP 管理設定
Guest WiFi Portal設定
流量監控
Fast Roaming
快速設定WiFi漫遊
| Features | WAC564 |
| Frequency | 2.4GHz and 5GHz |
| Wireless Mode (Transmit x Receive) | 802.11ac (2x2)/ 802.11ac (4x4) |
| 802.11ac Wave | Wave 2 |
| Multi-User MIMO | Yes |
| Maximum Theoretical Throughput | 3Gbps AC3000 |
| Maximum Throughput (2.4/5GHz) | 400/867/1733Mbps (2.4/5/5GHz) |
| Centralized Management | Standalone - Insight app/Cloud Portal |
| SNMP | v1, v2c |
| Secure Socket Layer (SSL) | Yes |
| Router Mode | No |
| Repeater | Yes |
| Bridge point-to-point/multi-point | Yes |
| Separate bridge and access point | Yes |
| Antenna | Internal 3/4dBi (2.4/5GHz) |
| Wi-Fi Protected Access (WPA/WPA2), 802.11i | Yes |
| MAC address filtering with access control | Yes |
| 802.1x RADIUS support with EAP TLS, TTLS, PEAP | Yes |
| Rogue AP detection | Yes |
| Block SSID Broadcast | Yes |
| VLAN Support | Yes |
| Guest Network/Captive Portal | Yes |
| Easy ceiling mounting/wall mouting | Yes |
| Bandwidth management | Yes |
| Link Layer Discovery Protocol | Yes |
| Bandsteering | Yes |
| Airtime fairness | Yes |
| Loadbalancing | Yes |
| Centralized Auto Tx Power and Auto Channel configuration done by Insight Instant Wi-Fi | Yes |
| Mobility: OKC for Layer 2 fast roaming | Yes |
| Max clients | Yes (Supports approximately 40 wireless clients) |
| Dual Ethernet | Yes |
| Gigabit Ethernet Ports | 4 |
| Technical Specification | |
| What do I need for WAC564 Mesh Extender to work? | At least one WAC540 access point with wired backhaul connection in extender mode -SOLD SEPARATELY wired backhaul connection in extender mode -SOLD SEPARATELY A router to connect the WAC564 in access point mode |
| AC3000 Mesh Extender | 1,733 + 866 + 400Mbps |
| Tri-band Wi-Fi Mesh System | Front haul Radio 1: IEEE® 802.11b/g/n 2.4GHz–256QAM support Front haul Radio 2: IEEE® 802.11a/n/ac 5GHz–256QAM support Backhaul Radio 3: IEEE® 802.11a/n/ac 5GHz–256QAM support |
| High-performance antennas with high-power amplifiers | Six (6) |
| Implicit/Explicit Beamforming for 2.4 & 5GHz bands | 1,733 + 866 + 400Mbps† |
| MU-MIMO capable for simultaneous data streaming to multiple devices | Yes |
| Gigabit LAN Ethernet ports | Four (4) 10/100/1000Mbps |
| Standards | |
| IEEE 802.11ac Wave 2 standard | Yes |
| WMM Wireless Multimedia Prioritization | Yes |
| WDS Wireless Distribution System | Yes |
| Security | |
| WPA/WPA2-PSK support | Yes |
| Support WPA-enterprise Radius server configura-tion for both security and accounting | Yes |
| Physical Specifications | |
| Dimensions (W x D x H) | 174 x 85 x 247 mm |
| Weight | 0.93kg |
| Network Management | |
| NETGEAR Insight Management for setup, monitoring and management | Yes |
| SNMP | v1, v2 |
| Advanced Wireless | |
| Wireless Distribution System (WDS) | Bridge mode: Point-to-point wireless Bridge mode: Point-to-multipoint wireless Repeater mode Adjustable Transmit Power Control (TPC) |
| Device detection | Identify type of wireless clients in the network |
| Warranty and Support | 5年保固 |
| All models | One (1) WAC564 Mesh Multi-Mode Access Point One (1) wall mount with screws One (1) ceiling mount with screws One (1) 12V/3.5A power adapter Installation guide |
如規格有異動，恕不另行通知。NETGEAR保有所有權利。
| Netgear Insight 無線功能 | |||
|---|---|---|---|
| 功能 | Basic | Premium | Pro |
| 最高可設定8組SSIDs，並可設定個人化登入入口，為不同角色創建不同網路(例如員工、客人)以確保安全 | ○ | ○ | ○ |
| 可為不同的無線網路(SSID)設定個別的VLAN，強化網路安全與流量分配效率 | ○ | ○ | ○ |
| SSID排程管理功能，可輕易控管開啟、關閉或管理WIFI的排程 | X | X | ○ |
| 無線加密(WPA/WPA2 – PSK & Enterprise)、URL過濾、MAC ACL等安全性功能 | ○ | ○ | ○ |
| 快速漫遊(Fast Roaming)提供更快的WIFI與更好的網路體驗 | ○ | ○ | ○ |
| 支援Facebook WIFI, 可讓訪問者在連線WIFI時連上企業Facebook增加曝光 | X | ○ | ○ |
| 支援Mesh WIFI，提升網路效能 | ○ | ○ | ○ |
| 偵測鄰近點 | ○ | ○ | ○ |
| 頻段＆頻道設定 | ○ | ○ | ○ |
| 監控所有連線者與流量，並提供圖表展示 | ○ | ○ | ○ |
| 存取點IP、LED設定 | ○ | ○ | ○ |
| 即時的無線資源管理，自動偵測WIFI訊號強度並調整最佳頻道 | ○ | ○ | ○ |
| VLAN允許存取三頻AP設定 | ○ | ○ | ○ |
| 支援Mesh WIFI | ○ | ○ | ○ |
| 支援Insight自有登入介面 | X | ○ | ○ |
| SSID排程 | X | X | ○ |
WAC564 規格
| Features | WAC564 |
| Frequency | 2.4GHz and 5GHz |
| Wireless Mode (Transmit x Receive) | 802.11ac (2x2)/ 802.11ac (4x4) |
| 802.11ac Wave | Wave 2 |
| Multi-User MIMO | Yes |
| Maximum Theoretical Throughput | 3Gbps AC3000 |
| Maximum Throughput (2.4/5GHz) | 400/867/1733Mbps (2.4/5/5GHz) |
| Centralized Management | Standalone - Insight app/Cloud Portal |
| SNMP | v1, v2c |
| Secure Socket Layer (SSL) | Yes |
| Router Mode | No |
| Repeater | Yes |
| Bridge point-to-point/multi-point | Yes |
| Separate bridge and access point | Yes |
| Antenna | Internal 3/4dBi (2.4/5GHz) |
| Wi-Fi Protected Access (WPA/WPA2), 802.11i | Yes |
| MAC address filtering with access control | Yes |
| 802.1x RADIUS support with EAP TLS, TTLS, PEAP | Yes |
| Rogue AP detection | Yes |
| Block SSID Broadcast | Yes |
| VLAN Support | Yes |
| Guest Network/Captive Portal | Yes |
| Easy ceiling mounting/wall mouting | Yes |
| Bandwidth management | Yes |
| Link Layer Discovery Protocol | Yes |
| Bandsteering | Yes |
| Airtime fairness | Yes |
| Loadbalancing | Yes |
| Centralized Auto Tx Power and Auto Channel configuration done by Insight Instant Wi-Fi | Yes |
| Mobility: OKC for Layer 2 fast roaming | Yes |
| Max clients | Yes (Supports approximately 40 wireless clients) |
| Dual Ethernet | Yes |
| Gigabit Ethernet Ports | 4 |
| Technical Specification | |
| What do I need for WAC564 Mesh Extender to work? | At least one WAC540 access point with wired backhaul connection in extender mode -SOLD SEPARATELY wired backhaul connection in extender mode -SOLD SEPARATELY A router to connect the WAC564 in access point mode |
| AC3000 Mesh Extender | 1,733 + 866 + 400Mbps |
| Tri-band Wi-Fi Mesh System | Front haul Radio 1: IEEE® 802.11b/g/n 2.4GHz–256QAM support Front haul Radio 2: IEEE® 802.11a/n/ac 5GHz–256QAM support Backhaul Radio 3: IEEE® 802.11a/n/ac 5GHz–256QAM support |
| High-performance antennas with high-power amplifiers | Six (6) |
| Implicit/Explicit Beamforming for 2.4 & 5GHz bands | 1,733 + 866 + 400Mbps† |
| MU-MIMO capable for simultaneous data streaming to multiple devices | Yes |
| Gigabit LAN Ethernet ports | Four (4) 10/100/1000Mbps |
| Standards | |
| IEEE 802.11ac Wave 2 standard | Yes |
| WMM Wireless Multimedia Prioritization | Yes |
| WDS Wireless Distribution System | Yes |
| Security | |
| WPA/WPA2-PSK support | Yes |
| Support WPA-enterprise Radius server configura-tion for both security and accounting | Yes |
| Physical Specifications | |
| Dimensions (W x D x H) | 174 x 85 x 247 mm |
| Weight | 0.93kg |
| Network Management | |
| NETGEAR Insight Management for setup, monitoring and management | Yes |
| SNMP | v1, v2 |
| Advanced Wireless | |
| Wireless Distribution System (WDS) | Bridge mode: Point-to-point wireless Bridge mode: Point-to-multipoint wireless Repeater mode Adjustable Transmit Power Control (TPC) |
| Device detection | Identify type of wireless clients in the network |
| Warranty and Support | 5年保固 |
| All models | One (1) WAC564 Mesh Multi-Mode Access Point One (1) wall mount with screws One (1) ceiling mount with screws One (1) 12V/3.5A power adapter Installation guide |
如規格有異動，恕不另行通知 © 2020著作權為NETGEAR所有。NETGEAR並保有所有權利。
