Model | Balance 20/30 | Balance One Core | 210 | 305 | 380 | 580 | 710 | 1350 | 2500 |
---|---|---|---|---|---|---|---|---|---|
適用對象 | 高端用戶&小型工作室 | 小型企業 | 中型企業 | 大型企業 | |||||
廣域乙太網路接口 | 2/3 | 2(GE) | 2(GE) | 3 (GE) | 3 (GE) | 5 (GE) | 7 (GE) | 13 (GE) | 12 (GE)/ 4 (GE) & 2 (10G SFP+) *10 |
LAN Ports | 4 (GE) | 8(GE) | 7 (GE) | 3 (GE) | 3 (GE) | 3 (GE) | 3 (GE) | 3 (GE) | 8( GE) / 2 (10G SFP+) * 10 |
USB WAN Modem Port *1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
4G LTE Module Built-in | ○ | ○ | ○ | ○ | ○ | ○ | ○ | ○ | ○ |
Wi-Fi Interface | ○ | ○ | ○ | ○ | ○ | ○ | ○ | ○ | ○ |
Recommended Users *2 | 1-60 | 1-60 | 25-150 | 50-500 | 50-500 | 300-1000 | 500-2000 | 1000-5000 | 5000-20000+ |
Stateful Firewall Throughput *3 | 150Mbps | 600Mbps/400Mbps *6 | 350Mbps | 1Gbps | 1Gbps | 1.5Gbps | 2.5Gbps | 5Gbps | 8Gbps |
Load Balancing/Failover | ● | ● | ● | ● | ● | ● | ● | ● | ● |
Drop-In Mode | ○ | ○ | ● | ● | ● | ● | ● | ● | ● |
Inbound Load Balancing | ○ | ○ | ● | ● | ● | ● | ● | ● | ● |
SpeedFusion Bandwidth Bonding | ○ | ○ | ● | ● | ● | ● *14 | ● | ● | ● |
Number of SpeedFusion Peers *4 | 2/5 *12 | 2/5/20 *13 | 2/5 *12 | 2/30 *8 | 30/100 *14 | 50/100 *14 | 300 | 800 | 4000 |
SpeedFusion Throughput *3 | 30Mbps | 30Mbps | 80Mbps | 150Mbps | 150Mbps | 200Mbps | 400Mbps | 800Mbps | 2Gbps |
SpeedFusion Throughput (No Encryption) *3 | 60Mbps | 60Mbps | 150Mbps | 150Mbps | 150Mbps | 200Mbps | 400Mbps | 800Mbps | 2Gbps |
L2TP / PPTP VPN Server | ● | ● | ● | ● | ● | ● | ● | ● | ● |
IPsec VPN (Network-to-Network) | ● | ● | ● | ● | ● | ● | ● | ● | ● |
Manage Pepwave AP | ● | ● | ● | ● | ● | ● | ● | ● | ● |
Maximum Number of AP Supported | 10 | 10 | 30 | 50 | 50 | 100 | 250 | 500 | 1500 |
Manage Remote AP & Multiple Config Profiles | ○ *9 | ○ *9 | ○ *9 | ● *9 | ● *9 | ● *9 | ● *9 | ● *9 | ● *9 |
Bandwidth Usage Monitor | ● | ● | ● | ● | ● | ● | ● | ● | ● |
QoS for VoIP and E-commerce | ● | ● | ● | ● | ● | ● | ● | ● | ● |
User Groups Bandwidth Control | ● | ● | ● | ● | ● | ● | ● | ● | ● |
Web Blocking | ● | ● | ● | ● | ● | ● | ● | ● | ● |
Web Filtering Blacklist | ○ | Lite | Lite | Full | Full | Full | Full | Full | Full |
1U Rackmount | ○ | ○ | ● | ● | ● | ● | ● | ● | ● |
High Availability | ○ | ○ | ● | ● | ● | ● | ● | ● | ● |
LAN Bypass *5 | ○ | ○ | ○ | ● | ● | ● | ● | ● | ● |
Dual Hot Swap Power Supply | ○ | ○ | ○ | ○ | ○ | ○ | ○ | ○ | ● |
*1 For a list of supported modems, please refer to: http://www.peplink.com/modem | |||||||||
*2 Recommendation for sizing purposes only. No software restrictions applied. | |||||||||
*3 Router and SpeedFusion Throughput is based on Ethernet frame sizes of 1280 or 1518 bytes. Actual performance can vary across different networking environments. Figures apply to the latest hardware revision. | |||||||||
*4 Number of peer Peplink or Pepwave devices you can connect using SpeedFusion. | |||||||||
*5 The Balance 20 and 210 has 2 WAN ports activated by default. The third WAN port can be activated by an optional license key. | |||||||||
*6 If the WAN Activation License (BPL-ONE-LC-5WAN) is activated, router throughput will be changed to 400Mbps, both number of WAN and LAN will become 5. | |||||||||
*7 Available in BPL-ONE. | |||||||||
*8 Balance 305 supports 2 SpeedFusion peers. It supports up to 30 SpeedFusion peers with purchase of SpeedFusion License (BPL-305-SPF). | |||||||||
*9 Balance 20/30 LTE/One/210/310 comes with AP Controller Standard, which supports up to two configuration profiles with multiple SSIDs, meaning that all APs will share the same configuration, and you can only manage APs on the local physical LAN. Balance 305/380/580/710/1350/2500 comes with AP Controller Pro, which supports multiple configuration profiles with multiple SSIDs, and you can manage remote APs outside the local physical LAN. | |||||||||
*10 Balance 2500 is available in two configurations with different LAN interfaces. | |||||||||
*11 SFP+ fiber module (transceiver) is not included. | |||||||||
*12 2 PepVPN Peers are enabled by default. Can be increased to 5 Peers using license PVN-LC-05. | |||||||||
*13 2 PepVPN Peers are enabled by default. Can be increased to 5 Peers using license PVN-LC-05 or to 20 Peers using license MAX-HD-020-SPF. | |||||||||
*14 30/50 SpeedFusion Peers are enabled by default for Balance 380/580 respectively. Can be increased to 100 Peers with purchase of SpeedFusion Bonding license SFN-LC-100. | |||||||||
*15 Available as a license add-on. |
