技術規格

FeaturesFS728TP
10/100Mbps ports24
Gigabit ports4
SFP ports2 (combo)
# of PoE ports24
Total PoE Power budget (Watts)192
Max MAC entries4K
Buffer size1MB
EEE-
FAN1
Acoustic Noise Level @25C (dBA)38.1
MTBF237,497 hrs
L2 SERVICES - VLANS
VLAN (# Supported)128
IEEE 802.1Q VLAN TaggingYes
Port- based VLANNo
IP based VLANsYes
MAC based VLANsYes
Voice VLANBased on phones OUI bytes (internal database, or user-maintained) or protocols (SIP, H323 and SCCP)
NETWORK SECURITY
IEEE 802.1x Radius Port Access AuthenticationMD5 (except FS750T2)
Guest VLANYes
RADIUS AccountingYes
MAC lockdown by the number of MACsYes
Dynamic learned entries per port128
Static entiries per port20
Network Storm Protection, DoSYes
Broadcast, Unicast, Multicast DoS ProtectionYes
DoS attacksYes
IP-based ACLsYes
MAC (Trusted MAC)Yes
L4 ACLYes
Protected PortYes
L2 SERVICES - AVAILABILITY
IEEE 802.3ad - LAGsYes
LACPYes ( (8 LAGS with max. of 8 members in each LAG))
Broadcast Storm ControlYes
IEEE 802.3x (Full Duplex and flow control)Yes
IEEE 802.1D Spanning Tree ProtocolYes
IEEE 802.1w Rapid Spanning TreeYes
IEEE 802.1s Multiple Spanning TreeYes
BPDU GuardYes
DoS PreventionYes
PoE TimerYes
L2 SERVICES - MULTICAST FILTERING
IGMP Snooping (v1, v2c and v3)Yes
Max. Multicast Group512
IGMP Snooping queriesYes
Block unknown MulticastYes
L3 SERVICES - DHCP
DHCP FilterYes
DHCP ClientYes
NETWORK MONITORING AND DISCOVERY SERVICES
802.1ab LLDP and LLDP-MEDYes
SNMPv1, v2c, v3
RMON 1,2,3,9Yes
ifTableYes
QUALITY OF SERVICE (QOS)
Number of Priority Queues8
TCP/UDP-baesd QoSYes
Rate limitingEgress only
DiffServ QoSYes
IEEE 802.1p COSYes
Dst MAC and IPYes
IPv4 DSCPYes
IPv4 TOSNo
Strick, or WRR (Weighted Round Robin)Both
Auto-VoIPYes, based on protocols (SIP, H323 and SCCP) or on OUI bytes (default database and user-based OUIs) in the phone source MAC address
Auto VideoNo
Port Mirroring (ingress and egress)Yes
IEEE NETWORK PROTOCOLS• IEEE 802.3 Ethernet
• IEEE 802.3i 10BASE-T
• IEEE 802.3u 100BASE-T
• IEEE 802.3ab 1000BASE-T
• IEEE 802.1Q VLAN Tagging
• IEEE 802.3x full-duplex flow control
• IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX
• IEEE 802.3ad Trunking (LACP)
• IEEE 802.1AB LLDP with ANSI/TIA-1057 (LLDP-MED)
• IEEE 802.1p Class of Service
• IEEE 802.3 af (PoE)
• IEEE 802.1D Spanning Tree (STP)
• IEEE 802.1s Multiple Spanning Tree (MSTP) (FS728TP Only)
• IEEE 802.1w Rapid Spanning Tree (RSTP)
• IEEE 802.1x (MD5) Radius network access control (except FS750T2)
MANAGEMENT
Password managementYes
Configurable Management VLANYes
Admin access control via RadiusYes
Admin access control via TACACS+Yes
Web-based graphical user interface (GUI)Yes
Smart Control Center (SCC) for
multi-switch management
Yes
Dual Software (firmware) imageYes
Dual Configuration fileNo
Cable Test utilityNo
File transfers (uploads, downloads)TFTP / HTTP
HTTP Download (firmware)Yes
LEDs
Per portSpeed, Link, Activity
Per devicePower, Fan and PoE Power Status (PoE model only)
PHYSICAL SPECIFICATIONS
Weight (kg)3.57
Dimensions (WxDxH) mm440x257x43
POWER CONSUMPTION (WHEN ALL PORTS USED, LINE-RATE TRAFFIC AND MAX POE IF APPLICABLE)
Worst case, all ports used, line-rate traffic, max PoE256w
ENVIRONMENTAL SPECIFICATIONS
Operating
Operating Temperature32° to 122°F (0° to 50°C)
Humidity90% maximum relative humidity, non-condensing
Altitude10,000 ft (3,000 m) maximum
Storage
Storage Temperature– 4° to 158°F (–20° to 70°C)
Humidity95% maximum relative humidity, non-condensing
Altitude10,000 ft (3,000 m) maximum
ELECTROMAGNETIC EMISSIONS AND IMMUNITY
CertificationsCE mark, commercial
FCC Part 15 Class A, VCCI Class A
Class A EN 55022 (CISPR 22) Class A
Class A C-Tick
EN 61000
EN 55024
CCC (except FS526T)
SAFETY
CertificationsCE mark, commercial
CSA certified (CSA 22.2 #950)
UL listed (UL 1950)/cUL IEC 950/EN 60950
保固五年



如規格有異動,恕不另行通知 © 2019著作權為NETGEAR所有。NETGEAR並保有所有權利。

FS728TP Datasheet
