JGS516

技術規格

FeaturesJGS516
Network Ports16 10/100/1000Mbps
Ethernet RJ-45 ports
效能規格
Switching bandwidth· 32Gbps
Forwarding Rate· 10 Mbps port: 14,880 frames/sec
· 100 Mbps port: 148,800 frames/sec
· 1000 Mbps port: 1,488,000 frames/sec
Latency (using 64 byte packets)· 10Mbps: 35μs (max)
· 100Mbps: 30μs (max)
· 1000Mbps: 15μs (max)
RAM buffer· 256KB
MAC address database· 8K
Mean time between failures (MTBF)· 441,123 hours
功耗· Power cord: 100-240V; 50-60Hz; plug is localized to country of sale
· 11.8W max
Standards Compliance• IEEE 802.3i 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet
• IEEE 802.3x fl ow control
• IEEE 802.3 CAMA/CD
• IEEE 802.3az Energy Efficient Ethernet
• Jumbo frame support (up to 9KB)
LEDs提示燈
Unit· Power
Per network port:· Link, activity, speed
體積與重量
Dimensions (w x d x h)· 328 x 169 x 43mm (12.9 x 6.7 x 1.7in)
Weight· 1.47kg (3.24lb)
環境需求
Operating temperature· 32° to 122°F (0° to 50°C)
Operating humidity· 90% maximum relative humidity, non-condensing
Storage temperature· -4° to 158ºF (-20° to 70°C)
Storage humidity· 10 to 95% relative humidity
電磁輻射干擾與耐受性· CE Class A, including EN 55022
· (CISPR 22) and EN 55024
· FCC Part 15 Class A
· VCCI Class A
· C-Tick Class A
· KCC
· CCC
安全認證· UL (UL 60950-1)/ cUL
· CE LVD (EN 60950-1)
· CB
· KCC
· CCC
· RU EAC
系統要求· UTP Category 5 cables or better
· Network software (e.g., Windows®, Mac® OS, Linux)
保固台灣公司貨享5年保固



如規格有異動,恕不另行通知 © 2019著作權為NETGEAR所有。NETGEAR並保有所有權利。
